UHP 600mm Graphite Electrodes
shanchuncarbon
- 1shanchuncarbon
- 2shanchuncarbon
- 3shanchuncarbon
SHANCHUNCARBON’s UHP 600mm Graphite Electrodes represent a premium diameter within our UHP Graphite Electrodes range. Designed for high-performance steelmaking and metallurgical applications, these electrodes deliver outstanding electrical conductivity, mechanical strength, and thermal stability. They ensure reliable operation in Electric Arc Furnaces (EAF) and Ladle Furnaces (LF), even under the most demanding conditions.
Graphite electrode Dimension
● Nominal Diameter: 610mm (min 607mm, max 613mm)
● Nominal Length: 2700 mm±10%
● Nipple: 317T4 (Long Type)
● Nipple Length: 457.2 mm
● Typical Weight: Electrodes and Nipple Approx.1220 kg
Graphite Nipple Dimension
Nipple Type: 317T4L
Nipple Diameter: 317.5 mm
Nipple Length: 457.2 mm
Nipple Socket Depth: 234.6 mm
Physical and Chemical Parameters of UHP600mm Graphite Electrode
| Index | Unit | YB/T4090 Industry Standard | |
| UHP 610mm | |||
| Typical Value | |||
| LSR≤ | Electrode | μΩ.M | 5.5 |
| Nipple | 3.8 | ||
| Flexural Strength ≥ | Electrode | Mpa | 11.0 |
| Nipple | 20.0 | ||
| Elastic Modulus ≤ | Electrode | Gpa | 14.0 |
| Nipple | 22.0 | ||
| Bulk Density ≥ | Electrode | g/cm³ | 1.66 |
| Nipple | 1.75 | ||
| CTE ≤ | Electrode | 10-6/ ℃ | 1.1 |
| Nipple | 0.9 | ||
| Ash ≤ | % | 0.3 | |
| Current Carrying Capacity | A | AC 70000-90000DC 750000-100000 | |
Advantage
● Withstand large currents, high discharge rate.
● Good dimension stability, not easy to deform.
● Resistant to cracking & spalling.
● High resistance to oxidation and thermal shock.
● High mechanical strength, low electrical resistance.
● High machining accuracy, good surface finishing.
