UHP 500mm Graphite Electrodes are a premium size option within our UHP Graphite Electrodes range, designed for reliable performance in steelmaking and metallurgical processes. Alongside UHP, we also offer HP Graphite Electrodes and RP Graphite Electrodes, providing a full spectrum of graphite solutions to meet diverse furnace requirements. Our electrodes are fully compatible with Graphite Nipples for seamless installation and operation. For more technical insights into graphite electrodes and their applications, visit the World Steel Association.
Graphite electrode Dimension
● Nominal Diameter: 500mm (min 505 mm, max 511 mm)
● Nominal Length: 2100 mm (+100mm,-100mm)
● Nipple: 269 4T4L
● Nipple Diameter: 269.88 mm
● Nipple Length: 457.2 mm
● Typical weight of electrodes: 860kg
● Application: steel melt plant, ladle furnace
● Current Carrying Capacity, (kA): 43-63
UHP500mm Graphite Electrode Physical and Chemical Parameters
| UHP700mmElectrodes | Bulk Density | Resistance | Flexual Strength | Young’s Modulue | ThermalExpansion | Ash |
| Unit | g/cm³ | μΩ.M | Mpa | Gpa | 10-6/ ℃ | % |
| Electrode | 1.65-1.72 | 4.5-5.8 | 8.5-11.5 | 6.0-9.5 | 1.5 | 0.3 |
| Nipple | 1.73-1.81 | 3.5-5.0 | 12.4-20.0 | 12.0-18.0 | 1.4 | 0.3 |
Advantage
● Withstand large currents, high discharge rate
● Good dimension stability, not easy to deform
● Resistant to cracking & spalling
● High resistance to oxidation and thermal shock
● High mechanical strength, low electrical resistance
● High machining accuracy, good surface finishing
